Belt Press NBD-M TYPE
- Multi-angle rotary high performance device
- Drum consists of a strong filter cloth with a suitable mesh size, rotating to separate water and sludge
- Suitable used in high concentration (s.s) sludge
- Brings out 5~8% solid contents with 1~2% inlet s.s
- Broadly application in industrial sludge
Model |
Belt
Width (mm) | Capacity
(m3/hr) | Dry Sludge
(Kg DS/hr) | Belt
Velocity
(M/min) | Usage Power (HP) | Wash
Water
(m3/hr) | Frame
Dimensions
(L.W.H)
mm | Weight
(kg) |
| Drive | Flocculation
Tank
| Rotary Drum Screen |
NBD-M50 | 500 | 1~3 | 15~45 | 2~8 | 1/2 | 1/4 | 1/4 | 3.8 | 2439
1047
1881 | 860 |
NBD-M75 | 750 | 2.5~5 | 37~75 | 2~8 | 1/2 | 1/4 | 1/4 | 5.3 | 2439
1284
1881 | 940 |
NBD-M100 | 1000 | 3.5~7 | 52~105 | 2~8 | 1/2 | 1/4 | 1/4 | 7.2 | 2486
1534
1861 | 1020 |
NBD-M125 | 1250 | 5~9 | 75~135 | 2~8 | 1/2 | 1/4 | 1/4 | 8.7 | 2486
1784
1861 | 1100 |
